Name of Panel: BIS Certified Polycrystalline Modules 270 Watt 60 Cell Solar Panel
Model Number: Rhine 60 Cell Series 270wp
Capacity of Panel: 270 Watt
Maximum Efficiency: 17%
Weight in Gram/KG: 18 kg Approx.
Dimensions (L x W x H): 1651 x 991 x 35 mm 3
Solar Cells: Polycrystalline 156.75 mm x 156.75 mm
Cell Orientation: 60 Cells (10 x 6)
Front Glass: 3.2mm toughened textured glass
Back Sheet: White
Frame: Anodized Aluminum Alloy
Junction Box, Cable & Connectors: IP67, 3 Diode, 4mm 2 AWG 1000V MC4 connectors
Performance/Efficiency of Panel:Short-Circuit Current (Isc): 8.96 Amps, Operating Voltage (Vmp): 31.85 V, Optimum Operating Current (Imp): 8.48 Amps, Open-Circuit Voltage (Voc): 38.16 Volt, Module Efficiency: 17%; Operating Temperature: -40o C to 80o C, Maximum System Voltage: 1000 V, Maximum Series Fuse Rating: 20 Amp, Application Classification: Class A, Power Tolerance: +- 3%
Warranty: 10 Year Product Workmanship Warranty. 25 years Linear Power Warranty
Package includes: Solar Panel with Junction Box and Cable
Application of Panel: Best for Residential & Commercial installation, Solar Water Pumps, Solar Projects, Filling Stations, EV Charging Stations. Pre-drilled holes on the back of the panel for fast mounting and securing. Best compatible with 24V Inverter and Battery (Two battery of 12V each)
Features of Panel: Solar panels are BIS certified as per IS/IEC standards; Space Requirement-18 sq. feet (approx.) for single panel and 1000mm length meter cable for connection; Comes with premium MC4 connecting plugs which ensures a reliable connection.
Designed using a silver anodized high-tech aluminum frame that withstands higher wind and snow loads up to 4000/5400 Pa (IEC) which allows the panels to last for decades
Equipped with high-performance Grade A solar cells with PID resistant technology. The Grade A silicone cells come integrated with a powerful reflector that redirects sunlight back from the cell. This technology leads to the generation of up to 5 percent more power
Rhine Solar Limited is the manufacturer of solar panel modules in India with highest quality and durability of solar cells known today in domestic market. All our solar panels comes with long term warranty which gives confidence to our customers that they are buying quality product with Rhine Solar. To install these solar panels at your home, office or factory, please contact your local solar energy consultant who can easily get them assemble and install as per your requirements.
The capacity of this solar panel is 270watt with maximum efficiency of 16.50% which is very good consider to many competitors brand available in the market. This solar panel has 60 cells high quality solar cells and it weight 17kg approximates. This solar panel comes with junction box, cables and connectors which require at the time of installation.
Rhine Solar panel are made of durable 3.2mm toughened textured glass with white sheet on back and require little to no maintenance for the 25 or more years that they will generate power. In most cases, you don’t even need to clean your solar panels regularly. You can rely on Rhine Solar's 270watt solar panels.
Solar panels are a great solution to help power your home and make it more sustainable. Solar is also one of the leading clean energy sources in the world. But there are many different solar panel technologies out there, each with their own benefits and drawbacks. Find out about different types of panels and which might be right for you!
