550 Watt Mono Perc Solar Panel Order Online

550 Watt Half Cut Mono Perc Solar Panel Best Price

Name of Panel: BIS Certified Half Cut Mono Perc Module 550 Watt 144 Cell Solar Panel

Model Number: Rhine 144 Cell Series 550wp (RSL550M)

Capacity of Panel: 550 Watt

Maximum Efficiency: 21.00%

Weight in Gram/KG: 27.90 kg Approx.

Dimensions (L x W x H): 2278 x 1134 x 35 mm ³

Solar Cells: Monocrystalline 91 mm x 182 mm

Cell Orientation: 144 cells (12 x 12)

Front Glass: 3.2mm toughened textured glass

Back Sheet: White

Frame: Anodized Aluminum Alloy

Standard Packing: 25/29 Panels per pallet

Module Pieces per Container: 600 Pieces/Modules/Panels ( 40 HQ )

Junction Box, Cable & Connectors: IP 68 split junction box, 3 Diode, 4mm ² AWG 1500V MC4 connectors

Performance/Efficiency of Panel: Short-Circuit Current (Isc): 13.46 Amps, Operating Voltage (Vmp): 44.21 V, Optimum Operating Current (Imp): 12.45 Amps, Open-Circuit Voltage (Voc): 49.68 Volt, Module Efficiency: 21.0%; Operating Temperature: -40^o C to 80^oC, Maximum System Voltage: 1500 V, Maximum Series Fuse Rating: 25 Amp, Application Classification: Class A, Power Tolerance: +- 3%

Warranty: 10 Year Product Workmanship Warranty. 25 years Linear Power Warranty

Package includes: Solar Panel with Junction Box and Cable

Application of Panel: Best for Residential & Commercial installation, Solar Water Pumps, Solar Projects, Filling Stations, EV Charging Stations. Pre-drilled holes on the back of the panel for fast mounting and securing. Best compatible with 24V Inverter and Battery (Two battery of 12V each)

Features of Panel: Solar panels are BIS certified as per IS/IEC standards; Space Requirement – 20 sq. feet (approx.) for single panel and 1000mm length meter cable for connection; Comes with premium MC4 connecting plugs which ensures a reliable connection.

Designed using a silver anodized high-tech aluminum frame that withstands higher wind and snow loads up to 4000/5400 Pa (IEC) which allows the panels to last for decades

Equipped with high-performance Grade A solar cells with PID resistant technology. The Grade A silicone cells come integrated with a powerful reflector that redirects sunlight back from the cell. This technology leads to the generation of up to 5 percent more power

• Rhine 550W 24V Mono Perc Half Cut Solar Panel is a premium quality product. Rhine Mono Perc Half Cut Solar Panel are manufactured by using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field. Rhine Mono Perc Half Cut Solar Panel are encapsulated by tempered glass and waterproof resin, it is strong and durable, and its service life is generally longer. High Efficiency Solar Panels is mostly used in the production of high-quality system to generate electricity, and the conversion efficiency is higher than that of polycrystalline solar panels. All materials used to manufacture Rhine Solar Panel, are sourced from the most reliable and official vendors, chosen after performing detailed market surveys.

  • SUPERIOR PRICE PERFORMANCE
  • EFFECTIVE GAIN OF 1% OF CELL ACTIVE AREA
  • BETTER TOLERANCE TO MICRO CRACK
  • LCOE IS CUT BACK by using M10 size solar cell with adding more power output than lower size cell module
  • HIGHER NUMBER OF BUSBAR makes the PV modules less prone to loss in efficiency and increase tolerance to micro cracks
  • Implementation of bypass diodes in split JB series-parallel connections enable the module to perform in PARTIAL
  • CYLINDRICAL TABBING WIRE is used to reduce the shadow on cell active area
• The benefits of Mono Perc Solar Panels are many:
  1) They're more efficient than any other solar panel type. A mono-perovskite solar panel has an efficiency rate of up to 25%, whereas a standard silicon solar panel has an efficiency rate of only around 15%. This means that you'll get more electricity from your system with a mono-perovskite panel than you would with a standard silicon panel.

  2) They can be used in areas with low sun exposure, like cloudy climates or at higher altitudes where there's less direct sunlight reaching the ground below you. The increased efficiency means that they'll produce more power even in these situations than standard silicon panels would be able to produce without additional shading or reflective coatings on the surface of each individual pane itself (which would require additional installation costs).

  3) They also have very low-iron technology which makes them more effective in absorbing heat from sunlight. This means that they can generate energy at lower temperatures than other types of solar panels and reduce energy losses by up to 70%.

Frequently Asked Question on 550 Mono Perc Panel (1 to 5)
Q1. What is the capacity of the Rhine 144 Cell Series 550wp solar panel?
A1. The Rhine 144 Cell Series 550wp solar panel has a capacity of 550 Watts.


Q2. What is the maximum efficiency of the Rhine 144 Cell Series 550wp solar panel?
A2. The maximum efficiency of the Rhine 144 Cell Series 550wp solar panel is 21.00%.


Q3. What are the dimensions of the Rhine 144 Cell Series 550wp solar panel?
A3. The dimensions of the Rhine 144 Cell Series 550wp solar panel are 2278 x 1134 x 35 mm^3 (L x W x H).


Q4. What is the warranty coverage for the Rhine 144 Cell Series 550wp solar panel?
A4. The Rhine 144 Cell Series 550wp solar panel comes with a 10-year product workmanship warranty and a 25-year linear power warranty.


Q5. What applications is the Rhine 144 Cell Series 550wp solar panel best suited for?
A5. The Rhine 144 Cell Series 550wp solar panel is best suited for residential and commercial installations, solar water pumps, solar projects, filling stations, and EV charging stations. It is also compatible with 24V inverters and batteries (two batteries of 12V each).
FAQ on Rhine Solar 550 Watt Mono Perc Solar Panel (6 to 10)
Q6. What type of solar cells are used in the Rhine 144 Cell Series 550wp solar panel?
A6. The Rhine 144 Cell Series 550wp solar panel uses monocrystalline solar cells that measure 91 mm x 182 mm.


Q7. What is the composition of the front glass on the Rhine 144 Cell Series 550wp solar panel?
A7. The front glass of the Rhine 144 Cell Series 550wp solar panel is made of 3.2mm toughened textured glass.


Q8. How is the Rhine 144 Cell Series 550wp solar panel framed?
A8. The solar panel is framed with an anodized aluminum alloy frame, providing durability and resistance to environmental conditions.


Q9. What is included in the standard packing of the Rhine 144 Cell Series 550wp solar panel?
A9. The standard packing includes 25/29 panels per pallet for the Rhine 144 Cell Series 550wp solar panel.


Q10. What is the operational temperature range of the Rhine 144 Cell Series 550wp solar panel?
A10. The Rhine 144 Cell Series 550wp solar panel has an operating temperature range of -40°C to 80°C, ensuring its efficiency across various environmental conditions.


Questions on Rhine's Mono Perc Solar Panel (11 to 15)
Q11. What is the package content when purchasing the Rhine 144 Cell Series 550wp solar panel?
A11. When purchasing the Rhine 144 Cell Series 550wp solar panel, the package includes the solar panel itself with the junction box and cable.


Q12. Can the Rhine 144 Cell Series 550wp solar panel be used for specific applications?
A12. Yes, the Rhine 144 Cell Series 550wp solar panel is suitable for residential and commercial installations, solar water pumps, solar projects, filling stations, EV charging stations, and it's designed for compatibility with 24V inverters and batteries.


Q13. What technology is used in the solar cells of the Rhine 144 Cell Series 550wp solar panel?
A13. The solar cells in the Rhine 144 Cell Series 550wp solar panel utilize Grade A silicone cells with PID resistant technology and a powerful reflector, resulting in up to 5% more power generation.


Q14. How does the frame of the Rhine 144 Cell Series 550wp solar panel enhance its durability?
A14. The solar panel is designed with a silver anodized high-tech aluminum frame, enabling it to withstand higher wind and snow loads up to 4000/5400 Pa (IEC), ensuring its longevity and durability.


Q15. What is the power tolerance of the Rhine 144 Cell Series 550wp solar panel?
A15. The power tolerance of the Rhine 144 Cell Series 550wp solar panel is +- 3%, providing consistency and reliability in power output.

Is there anything else you'd like to know or inquire about? Feel free to ask!
