20 Watt Made in India Solar Panels in Delhi India

20 Watt Made in India Solar Panels in Delhi India

Name of Panel: BIS Certified Polycrystalline Modules 20-Watt 36 Cell Solar Panel

Model Number: Rhine 36 Cell Series 20wp

Capacity of Panel: 20 Watt

Maximum Efficiency: 13.50%

Weight in Gram/KG: 2 kg Approx.

Dimensions (L x W x H): 275 x 666 x 22 mm

Solar Cells: Polycrystalline 22.00 mm x 156.75 mm

Cell Orientation: 36 Cells (9 x 4)

Front Glass: 3.2mm toughened textured glass

Back Sheet: White

Frame: Anodized Aluminum Alloy

Junction Box, Cable & Connectors: IP65.

Performance/Efficiency of Panel:Short-Circuit Current (Isc): 1.3 Amps, Operating Voltage (Vmp): 17.9 V, Optimum Operating Current (Imp): 1.13 Amps, Open-Circuit Voltage (Voc): 21.6 Volt, Module Efficiency: 13.5%; Operating Temperature: -40^o C to 80^o C, Maximum System Voltage: 600 V, Maximum Series Fuse Rating: 6 Amp, Application Classification: Class A, Power Tolerance: +- 3%

Warranty: 5 Year Product Workmanship Warranty. 10 years Linear Power Warranty

Package includes: Solar Panel with Junction Box.

Application of Panel: Best for use in home lighting & small battery charging. Pre-drilled holes on the back of the panel for fast mounting and securing. Best for 12 volts charging and multiple panels can be connected for 12-volt battery.

Features of Panel: Solar panels are BIS certified as per IS/IEC standards. Space Requirement 2 sq. feet (approx.) for single panel.

Designed using a silver anodized high-tech aluminum frame that withstands higher wind and snow loads up to 4000/5400 Pa (IEC) which allows the panels to last for decades.

Equipped with high-performance Grade A solar cells with PID resistant technology. The Grade A silicone cells come integrated with a powerful reflector that redirects sunlight back from the cell. This technology leads to the generation of up to 5 percent more power.

Frequently Asked Question on 20 Watt Solar Panel (1 to 5)
What is the capacity of the Rhine 36 Cell Series 20wp solar panel?
A1: The capacity of the Rhine 36 Cell Series 20wp solar panel is 20 Watts.


Q2: What is the maximum efficiency of the Rhine 20-Watt solar panel?
A2: The maximum efficiency of the Rhine 20-Watt solar panel is 13.50%.


Q3: What are the dimensions of the Rhine 20-Watt solar panel?
A3: The dimensions of the Rhine 20-Watt solar panel are 275 x 666 x 22 mm (Length x Width x Height).


Q4: What is the warranty period for the Rhine 20-Watt solar panel?
A4: The Rhine 20-Watt solar panel comes with a 5-year product workmanship warranty and a 10-year linear power warranty.


Q5: What is the recommended application for the Rhine 20-Watt solar panel?
A5: The Rhine 20-Watt solar panel is best for use in home lighting and small battery charging. It is designed for 12-volt battery systems and is suitable for connecting multiple panels for 12-volt battery charging.


FAQ on Rhine Solar 20 Watt Polycrystalline Panel (6 to 10)
Q6: What is the composition of the solar cells used in the Rhine 20-Watt solar panel?
A6: The solar cells in the Rhine 20-Watt solar panel are polycrystalline and measure 22.00 mm x 156.75 mm.


Q7: What is the material of the front glass of the Rhine 20-Watt solar panel?
A7: The front glass of the Rhine 20-Watt solar panel is made of 3.2mm toughened textured glass.


Q8: What is the frame of the Rhine 20-Watt solar panel made of?
A8: The frame of the Rhine 20-Watt solar panel is made of anodized Aluminum Alloy, designed to withstand higher wind and snow loads.


Q9: What is the recommended mounting space for a single Rhine 20-Watt solar panel?
A9: A single Rhine 20-Watt solar panel requires approximately 2 square feet of mounting space.


Q10: Can the Rhine 20-Watt solar panel withstand varying temperatures?
A10: Yes, the Rhine 20-Watt solar panel can operate in a temperature range of -40°C to 80°C, ensuring its functionality in diverse climates.


More Details on Rhine's 20W Solar Panel (11 to 15)
Q11: What is the package content when purchasing a Rhine 20-Watt solar panel?
A11: The package includes the Rhine 20-Watt solar panel with a Junction Box.


Q12: Is the Rhine 20-Watt solar panel BIS certified?
A12: Yes, the Rhine 20-Watt solar panel is BIS certified, adhering to IS/IEC standards.


Q13: What is the back sheet of the Rhine 20-Watt solar panel made of?
A13: The back sheet of the Rhine 20-Watt solar panel is white.


Q14: What is the classification of the Rhine 20-Watt solar panel in terms of application?
A14: The Rhine 20-Watt solar panel is classified as Class A for its application.


Q15: How is sunlight redirected in the Rhine 20-Watt solar panel to increase power generation?
A15: The Rhine 20-Watt solar panel uses Grade A solar cells with PID resistant technology and a powerful reflector that redirects sunlight back from the cell, leading to up to 5 percent more power generation.
