510 Watt DCR Mono Perc Solar Panel Made in India
Home/Store/DCR Solar Panels
Product Details

510 Watt DCR Mono Perc Solar Panel Price

Name of Panel: BIS Certified DCR Mono Perc Module 510 Watt 144 Cell Solar Panel

Model Number: Rhine 144 Cell Series 510wp (RSL510M)

Capacity of Panel: 510 Watt

Maximum Efficiency: 20.60%

Weight in Gram/KG: 27.90 kg Approx.

Dimensions (L x W x H): 2278 x 1134 x 35 mm 3

Solar Cells: Mono Perc 91 mm x 182 mm

Cell Orientation: 144 cells (12 x 12)

Front Glass: 3.2mm toughened textured glass

Back Sheet: White

Frame: Anodized Aluminum Alloy

Standard Packing: 25/29 Panels per pallet

Module Pieces per Container: 600 Pieces/Modules/Panels ( 40 HQ )

Junction Box, Cable & Connectors: IP 68 split junction box, 3 Diode, 4mm 2 AWG 1500V MC4 connectors

Performance/Efficiency of Panel: Short-Circuit Current (Isc): 12.73 Amps, Operating Voltage (Vmp): 44.21 V, Optimum Operating Current (Imp): 11.77 Amps, Open-Circuit Voltage (Voc): 49.68 Volt, Module Efficiency: 20.60%; Operating Temperature: -40o C to 80oC, Maximum System Voltage: 1500 V, Maximum Series Fuse Rating: 25 Amp, Application Classification: Class A, Power Tolerance: +- 3%

Warranty: 10 Year Product Workmanship Warranty. 25 years Linear Power Warranty

Package includes: Solar Panel with Junction Box and Cable

Application of Panel: Best for Residential & Commercial installation, Solar Water Pumps, Solar Projects, Filling Stations, EV Charging Stations. Pre-drilled holes on the back of the panel for fast mounting and securing. Best compatible with 24V Inverter and Battery (Two battery of 12V each)

Features of Panel: Solar panels are BIS certified as per IS/IEC standards; Space Requirement – 20 sq. feet (approx.) for single panel and 1000mm length meter cable for connection; Comes with premium MC4 connecting plugs which ensures a reliable connection.

Designed using a silver anodized high-tech aluminum frame that withstands higher wind and snow loads up to 4000/5400 Pa (IEC) which allows the panels to last for decades

Equipped with high-performance Grade A solar cells with PID resistant technology. The Grade A silicone cells come integrated with a powerful reflector that redirects sunlight back from the cell. This technology leads to the generation of up to 5 percent more power


  • Solar panels are devices that convert sunlight into electricity.
  • They are a sustainable and environmentally friendly source of electricity that can help reduce the world's dependence on fossil fuels. As the demand for solar energy increases, there are many different types of solar panels available in the market. Two of the most common types are DCR and non-DCR solar panels.

  • DCR panels are those solar panels or modules
  • wherein the solar cell and solar module are manufactured in India. Whereas, Non-DCR solar panels, on the other hand, are those solar panels in which the solar cell and solar module are not designed and manufactured in India.

    क्या इस पैनल ???

    Q1. क्या इस पैनल का वजन बताया गया है?

    A1. हाँ, इस पैनल का वजन 27.90 किलोग्राम (अनुमानित) है।

    Q2. इस पैनल का क्षमता क्या है?

    A2. यह पैनल 510 वॉट की क्षमता वाला है।

    Q3. क्या पैनल का अधिकतम प्रदर्शन और प्रदर्शन दक्षता बताई गई है?

    A3. हाँ, पैनल का अधिकतम प्रदर्शन 20.60% है और प्रदर्शन दक्षता भी 20.60% है।

    Q4. क्या इस पैनल का गोली दान और दुर्गमता से संबंधित कोई जानकारी है?

    A4. हाँ, इसमें मोनो पर्स सोलर सेल्स आहे जो 91 मिमी x 182 मिमी के हैं और इसमें 144 सेल्स (12 x 12) की ओरिएंटेशन है।

    Q5. इस पैनल के वारंटी के बारे में कुछ बताएं।

    A5. इस पैनल की उत्पाद शिल्प की वारंटी 10 साल है और विद्युत शक्ति की लीनियर वारंटी 25 साल है।

    Q6. क्या इस पैनल के लिए उपयुक्त अनुप्रयोगों के बारे में जानकारी दी गई है?

    A6. हाँ, इस पैनल को निवासीय और वाणिज्यिक स्थापना, सोलर पानी पंप, सोलर परियोजनाएँ, फिलिंग स्टेशन, ईवी चार्जिंग स्टेशन्स के लिए सर्वोत्तम माना गया है। इसमें पिछले भाग पर त्वरित स्थानन और सुरक्षित करने के लिए पैनल के पीछे पूर्व-ड्रिल किए गए होल्स भी हैं। यह 24V इन्वर्टर और बैटरी (प्रति बैटरी 12V की दो) के साथ सर्वोत्तम संगत है।

    Q7. क्या इस पैनल के विशेषताएं बताई गई हैं?

    A7. हाँ, इसमें यह बताया गया है कि सोलर पैनल BIS IS/IEC मानकों के अनुसार प्रमाणित हैं। इसके लिए एक पैनल के लिए लगभग 20 वर्ग फीट की आवश्यकता है और कनेक्शन के लिए 1000 मिमी लंबाई की केबल आती है। यह प्रीमियम MC4 कनेक्टिंग प्लग्स के साथ आता है जो एक मजबूत कनेक्शन सुनिश्चित करते हैं।

    Q8. क्या इस पैनल के फ्रेम के बारे में कुछ विशेष बताया गया है?

    A8. हाँ, यह विवरण दिया गया है कि यह पैनल एक चांदी रंग के एनोडाइज़्ड हाई-टेक एल्यूमिनियम फ्रेम का उपयोग करता है, जो उच्च हवा और बर्फ की भार से संबंधित अधिक भार से बचने में मदद करता है (4000/5400 Pa, IEC) जिससे पैनल दशकों तक टिक सकते हैं।

    Q9. क्या इस पैनल में उच्च प्रदर्शन वाले ग्रेड A सोलर सेल्स हैं?

    A9. हाँ, इसमें उच्च प्रदर्शन वाले ग्रेड A सोलर सेल्स शामिल हैं जिनमें PID प्रतिरोधी तकनीक से लैस हाई-परफॉर्मेंस ग्रेड A सिलिकॉन सेल्स शामिल हैं। ये सिलिकॉन सेल्स एक शक्तिशाली परामर्शक भित्तिक के साथ एकीकृत हैं जो सूर्यकिरण को सेल से वापस दिशा में पुनर्निर्देशित करता है। यह प्रौद्योगिकी पावर उत्पन्न करने में भी 5 प्रतिशत अधिक ऊर्जा उत्पन्न करती है।

    Q10. क्या इस पैनल के साथ कुछ अन्य शामिल है?

    A10. हाँ, पैकेज में यह शामिल हैं: सोलर पैनल, जंक्शन बॉक्स और केबल।

    Q11. क्या इस पैनल की जंटरनल बॉक्स, केबल और कनेक्टर्स के बारे में विवरण दिया गया है?

    A11. हाँ, इसमें IP 68 स्प्लिट जंटरनल बॉक्स, 3 डायड, 4 मिमी 2 AWG 1500V MC4 कनेक्टर्स शामिल हैं।

    Q12. क्या इस पैनल की प्रदर्शन/क्षमता के विवरण दिए गए हैं?

    A12. हाँ, इसमें लघुसंदूर धारा (Isc): 12.73 एम्प्स, ऑपरेटिंग वोल्टेज (Vmp): 44.21 वोल्ट, आदर्श ऑपरेटिंग धारा (Imp): 11.77 एम्प्स, खुला सर्किट वोल्टेज (Voc): 49.68 वोल्ट, मॉड्यूल की क्षमता: 20.60%; ऑपरेटिंग तापमान: -40°C से 80°C, अधिकतम सिस्टम वोल्टेज: 1500 वोल्ट, अधिकतम श्रृंखला फ्यूज़ रेटिंग: 25 एम्प्स, आवेदन वर्गीकरण: कक्षा ए, पावर टॉलरेंस: +- 3% दिए गए हैं।

    Q13. क्या इस पैनल के वारंटी विवरण दिए गए हैं?

    A13. हाँ, इस पैनल की उत्पाद शिल्प वारंटी 10 साल है और 25 साल की लीनियर पावर वारंटी भी है।
