Name of Panel: BIS Certified Monocrystalline Modules 390 Watt 72 Cell Solar Panel
Model Number: Rhine 72 Cell Series 390wp (RSL72FM-390Wp)
Capacity of Panel: 390 Watt
Maximum Efficiency: 20.00%
Weight in Gram/KG: 21 kg Approx.
Dimensions (L x W x H): 1970 x 990 x 40 mm 3
Solar Cells: Monocrystalline 156.75 mm x 156.75 mm
Cell Orientation: 72 cells (12 x 6)
Front Glass: 3.2mm toughened textured glass
Back Sheet: White
Frame: Anodized Aluminum Alloy
Junction Box, Cable & Connectors: IP67, 3 Diode, 4mm2 AWG 1000V MC4 connectors
Performance/Efficiency of Panel:Short-Circuit Current (Isc): 9.9 Amps, Operating Voltage (Vmp): 41.1 V, Optimum Operating Current (Imp): 9.5 Amps, Open-Circuit Voltage (Voc): 48.8 Volt, Module Efficiency: 19.6%; Operating Temperature: -40o C to 80oC, Maximum System Voltage: 1000 V, Maximum Series Fuse Rating: 20 Amp, Application Classification: Class A, Power Tolerance: +- 3%
Warranty: 10 Year Product Workmanship Warranty. 25 years Linear Power Warranty
Package includes: Solar Panel with Junction Box and Cable
Application of Panel: Best for Residential & Commercial installation, Solar Water Pumps, Solar Projects, Filling Stations, EV Charging Stations. Pre-drilled holes on the back of the panel for fast mounting and securing. Best compatible with 24V Inverter and Battery (Two battery of 12V each)
Features of Panel: Solar panels are BIS certified as per IS/IEC standards; Space Requirement – 20 sq. feet (approx.) for single panel and 1000mm length meter cable for connection; Comes with premium MC4 connecting plugs which ensures a reliable connection.
Designed using a silver anodized high-tech aluminum frame that withstands higher wind and snow loads up to 4000/5400 Pa (IEC) which allows the panels to last for decades
Equipped with high-performance Grade A solar cells with PID resistant technology. The Grade A silicone cells come integrated with a powerful reflector that redirects sunlight back from the cell. This technology leads to the generation of up to 5 percent more power
Manufactured from high-quality materials and certified by BIS, this solar panel is a cost-effective way of generating in your own home. Conforms to the IS/IEC standards and is BIS certified. Manufactured with high efficiency, long-term stability and high corrosion resistance. These panels have the right amount of power to save you time and money. Manufactured with high-quality, these solar panels are designed to withstand different weather conditions. Monocrystalline solar panels are made of mono-crystalline cells which are usually half the thickness of polycrystalline cells and are therefore more efficient. The conversion rate is between 18% and 22%.
